e the same as in Fig. 376 ;the pitch, however, is 33^. In the double-riveted lap-joint shown in Fig.378, the plate is fl, the rivets lyV. the holes aremade i| and the pitch is 3. A butt-joint with double cover plates is illus-trated in Fig. 379. Here the plate is | steel andi rivets. The inner… … POWER TRANSMISSION. The oft-repeated word transmission comes from two Latin words, trans, across, or over, and mittere,to send, hence, to carry from one place to another; the illustration of a few devices for the transmissionof power from its cause to its place of useful employment is the limit of…
