Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 285
Another gang die is shown in Figs. 463 and 465. Fig. 466 is the blank, Fig. 465 the top view of thelower die and stripper ; Fig. 464, a sectional view ofthe same ; and Fig. 463 shows the punch in section. … Fig. 469. T^G. 468. In Fig. 468 is shown a type of a die, which by itsrelative simplicity when compared with the workproduced, will always stand as a beautiful exampleof mechanical ingenuity. ROGERS DRAWING AND DESIGN. 313 It is a single-action cutting and drawing die, gen-erall)- called a…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
