five screws.The tee-square should be used with itshead held firmly against the left handedge of the board. Any number of hori-zontal lines may be drawn by sliding thetee-square up or down, Fig. 76. Another kind of a tee-square is shownin Fig. JJ. The blade of this tee-squareis fastened to the head… … Fig. 77.
