r of heavy parallellines, Fig. 141. which does not receive any direct light. The heavylines become lighter gradually and are drawn veryfine near the midde of the cylinder; after this thelines are again dra.vn slightly heavier up to the sideof the cylinder, which is nearest to the source ofthe…
