Rudiments of the art of building : represented in five sections [...] for the use of architects, builders, draghtsmen, machinists, engineers and mechanics (1853)
Bullock, John · New York : Stringer & Townsend · leaf 170
sible route, no matter howcircuitous, and the required levels are found by measuringup from the floors to the surface of the water, which will ofcourse stand at the same level at each end of the tube. WORKING DRAWINGS. 310. The architect, being furnished with the plan andlevels of the site of his… … 166 RUDIMENTS OF THE It is not sufficient for the execution of the working draw-ings that the draughtsman should be acquainted with theordinary principles of geometric projection. He must alsobe thoroughly conversant with perspective, and with theprinciples of chiascuro, or light and shade, or he…
