Rudiments of the art of building : represented in five sections [...] for the use of architects, builders, draghtsmen, machinists, engineers and mechanics (1853)
Bullock, John · New York : Stringer & Townsend · leaf 172
. These drawings consist of Flans of the founda-tions, and of the different stories of the building, and of theroofs ; Elevations of the different fronts ; and Sections show-ing the heights of the stories, and such constructive detailsas the scale will admit of. These drawings are carefullyfigured,… … verification in all stages of the work. This is best done byruling faint lines on the drawings, through the principaldivisions of the design, as shown in fig. 106, where the planand elevation are divided into compartments, by lines pass-ing through the centres of the columns, from which all…
Building
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
![An illustration from Rudiments of the art of building : represented in five sections [...] for the use of architects, builders, draghtsmen, machinists, engineers and mechanics, 1853, leaf 172](https://img.insideoutlibrary.com/img/1024/ia-rudimentsofartof00bull-172-78.webp)
