Rules and examples of perspective proper for painters and architects, etc. in English and Latin :‡bcontaining a most easie and expeditious method to delineate in perspective all designs relating to architecture, after a new manner, wholly free from the confusion of occult lines /‡cby that great master thereof, Andrea Pozzo, Soc. Jef. engraven in 105 ample folio plates, and adorn'd with 200 initial letters to the explanatory discourses ; printed from copper-plates ony best paper by John Sturt ; done into English from the original printed at Rome 1693 in Lat. and Ital. by Mr John James of Greenwich (1693)
Pozzo, Andrea · J Senex and R Gosling · leaf 136
Parallels are made to the Ground-line EF; andfrom the Interferons of thofe Parallels with the Vifuals, you complete the Delineation of the Plariin Perfpeclive. The Lines which in the Plan are Parallel to E F, being prolongd to the Vifual E O, are thencontinud parallel to the Perpendicular DE. And… … FIG U R A Trigefimafeptima. Deformatio Columns BTRUSCiE. X prdeparatione quam exhibuimus Figurd tri- gejtmafextd, eruitur columna h<zc nitida Or- dinis Etrufci, opt ice imminuta per latitudi- nes £^ altitudines partium Jtngularum $ qute accipiuntur ope duorum circinorum, ut f<e- piiis diSium…
