Rules and examples of perspective proper for painters and architects, etc. in English and Latin :‡bcontaining a most easie and expeditious method to delineate in perspective all designs relating to architecture, after a new manner, wholly free from the confusion of occult lines /‡cby that great master thereof, Andrea Pozzo, Soc. Jef. engraven in 105 ample folio plates, and adorn'd with 200 initial letters to the explanatory discourses ; printed from copper-plates ony best paper by John Sturt ; done into English from the original printed at Rome 1693 in Lat. and Ital. by Mr John James of Greenwich (1693)

Pozzo, Andrea · J Senex and R Gosling · leaf 167

An illustration from Rules and examples of perspective proper for painters and architects, etc. in English and Latin :‡bcontaining a most easie and expeditious method to delineate in perspective all designs relating to architecture, after a new manner, wholly free from the confusion of occult lines /‡cby that great master thereof, Andrea Pozzo, Soc. Jef. engraven in 105 ample folio plates, and adorn'd with 200 initial letters to the explanatory discourses ; printed from copper-plates ony best paper by John Sturt ; done into English from the original printed at Rome 1693 in Lat. and Ital. by Mr John James of Greenwich, 1693, leaf 167
The Plan of an IONICK Building, HE Geometrical Plan of this Ionick Work isA, underneath is its Perfpe&IveB; to ren-der which more diftind, the Ground-linethat in the following; Fiaures has only theDiftance PE from the Horizontal E O, ishere remov d downward to C B, as wasdone in the… … in2. The vifualLine OM is of the fame ufe as that of O T,in the Forty-third Figure; namely, to terminate the Lineswhich are drawn from the Members of the Plan B parallelto the Ground-line; from whence they are again contiriu dparallel to the Perpendicular E C, for making in Perfpec-tive the…
