Rules and examples of perspective proper for painters and architects, etc. in English and Latin :‡bcontaining a most easie and expeditious method to delineate in perspective all designs relating to architecture, after a new manner, wholly free from the confusion of occult lines /‡cby that great master thereof, Andrea Pozzo, Soc. Jef. engraven in 105 ample folio plates, and adorn'd with 200 initial letters to the explanatory discourses ; printed from copper-plates ony best paper by John Sturt ; done into English from the original printed at Rome 1693 in Lat. and Ital. by Mr John James of Greenwich (1693)
Pozzo, Andrea · J Senex and R Gosling · leaf 173
, ex vejiigio B figura quadragefimae-feptimte, ducere oportet parallelas ad line am plant CD, quauhi pervenerint ad vifualem OM, continuandcefunt cum aliisparallelis adlineam EC. Eafdemparallelas inhancfiguramtranjlatas Jecant vifuales ex linea reffa AB, in qua pojita funt altitudines adi-ficii… … The Forty-ninth FIGURE. The Elevation of the IONICK Dejign in PerfpeSlive. HIS Plate containing the Perfpective of the foregoingUpright, is drawn by the Method laid down in theForty-fecond Figure; to wit, from the Plan B of theForty-feventh Figure, Parallels to the Ground-line C Dare prolongd to…
