Rules and examples of perspective proper for painters and architects, etc. in English and Latin :‡bcontaining a most easie and expeditious method to delineate in perspective all designs relating to architecture, after a new manner, wholly free from the confusion of occult lines /‡cby that great master thereof, Andrea Pozzo, Soc. Jef. engraven in 105 ample folio plates, and adorn'd with 200 initial letters to the explanatory discourses ; printed from copper-plates ony best paper by John Sturt ; done into English from the original printed at Rome 1693 in Lat. and Ital. by Mr John James of Greenwich (1693)
Pozzo, Andrea · J Senex and R Gosling · leaf 215
the Parts of D to be painted larger, otherwife they willappear lefs than they really ought. And from hence you may difcern, why the Arch, which in theforemoft Frame would reach only to B, does in the hindmoft rife up to H. In the following Figure is fliewn the Manner of delineating the inner Frame,… … FIG U R A Sexagefimafecunda. De reticulandis telariis, qua: reprsfentent xdificia folida. 1)0 exemplaria tabernaculi qua Jeorfim delineanda funty conjunct im habes in A.1)trifque defervit eadem reticulatio, quam fuis numeris infignivimus. Toftquamervo defignaveris amplitudinem totius adificii, cum…
