Rules and examples of perspective proper for painters and architects, etc. in English and Latin :‡bcontaining a most easie and expeditious method to delineate in perspective all designs relating to architecture, after a new manner, wholly free from the confusion of occult lines /‡cby that great master thereof, Andrea Pozzo, Soc. Jef. engraven in 105 ample folio plates, and adorn'd with 200 initial letters to the explanatory discourses ; printed from copper-plates ony best paper by John Sturt ; done into English from the original printed at Rome 1693 in Lat. and Ital. by Mr John James of Greenwich (1693)

Pozzo, Andrea · J Senex and R Gosling · leaf 268

An illustration from Rules and examples of perspective proper for painters and architects, etc. in English and Latin :‡bcontaining a most easie and expeditious method to delineate in perspective all designs relating to architecture, after a new manner, wholly free from the confusion of occult lines /‡cby that great master thereof, Andrea Pozzo, Soc. Jef. engraven in 105 ample folio plates, and adorn'd with 200 initial letters to the explanatory discourses ; printed from copper-plates ony best paper by John Sturt ; done into English from the original printed at Rome 1693 in Lat. and Ital. by Mr John James of Greenwich, 1693, leaf 268
the Heights from the Eieta-tion. Here and henceforward, the Terms of Length and Height are made ufe of, as tho the Pianof each Perfpective were vertical $ according to which Supposition, I L is the Breadth of the Cor-bel, SR the Height, and RL the Length; whereas in reality SR is the Length, and RL… … FIGURA Oftogefima. Horizontals proje&io mutuliinumbrati. M hac Figura Juas umbras mutulo addidi-mus: eumque Ji in ahum fupra oculum ele-vaveris, £^ ex diftantia quam ipji dedi-musfufpexeris; miraberis profeffib, in aliumlonge concinniorem fubitb mutatum fuijje.
