ections for residentialstreets are shown. The above 45 feet and 50 feet roads are of ample width for average con-ditions in residential sections, subject to the 20 feet or 25 feet set-back of the buildings. See Page 99 Fig. 32 WHOLLY WITHIN DUCK MOUNTAIN FOREST RESERVE PLAN OF SUB DIVISION AT MADGE… … SPECIMEN PLAN OF SURVEY OF TOWN SITE This curved street plan of the townsite of Madge Lake, Saskatchewan, is a specimen of arevised system used by the Topographical Surveys Branch of the Department of the Interior tosecure conformity to contours of the land; but as designed it adds to rather than…
City planning · Public lands
