Sanitary arrangements for dwellings : intended for the use of officers of health, architects, builders, and householders (1874)

Eassie, William, 1832-1888 · London : Smith, Elder & Co. · leaf 134

An illustration from Sanitary arrangements for dwellings : intended for the use of officers of health, architects, builders, and householders, 1874, leaf 134
that exposed to the direct action of the fire inside thegrate. In the sketch here given the warmed air is ledinto the room from the two circular orifices seen at 6,but in some instances they are preferably placed at thesides of the chimney projection. Fire-clay casings are objected to by some on…

Heating · Water-supply · Ventilation · Lighting · Plumbing · Domestic engineering · Sanitary Engineering

Internet Archive · Medical Heritage Library · Public Domain Mark 1.0. Free to use for anything.
