d about 1^ incheswide, and divide it into six equal parts. At the end of the firstdivision from A fix the zero point, and to the right of thisfigure each division 1, 2, 3, 4, and 5. Divide AC into tenequal parts, and figure them from A towards C, then draw linesparallel to AB from one end of the… … ^ CO i9 t C( J^ 122 PRACTICAL PLANE GEOMETRY chap. and 0 draw lines parallel to 9C. Note.—The divisions betweenA and C are called diagonal divisions. To take off from tins scale a measurement equal to 273inches, we place one point of the dividers on the primarydivision figured 2, and the other on…
