Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics (1895)

Spanton, J. Humphrey (John Humphrey) · London : Macmillan · leaf 198

An illustration from Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics, 1895, leaf 198
sjnral of Jive revolutions on a givendiameter AB hy means of sem icircles. Divide AB into ten equal parts (Prob. 10). Bisect the sixthdivision from A in C (Prob. 1).With C as centre, and CK asradius, draw the semicircle KL.With K as centre, and radiusKL, draw the semicircle LH.With C as centre, and… … Fio:. 312. Problem 202.To construct an Archimedean sjnral of one revolution.Draw a circle and divide it by radii into any number of o Cl-^

Geometrical drawing
