Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics (1895)

Spanton, J. Humphrey (John Humphrey) · London : Macmillan · leaf 54

An illustration from Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics, 1895, leaf 54
• Fig. 89. Fig. 90. … O^ee Fig. 91. 34 PRACTICAL PLANE GEOMETRY

Geometrical drawing

Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
