Kirkman, Marshall Monroe, 1842-1921 · New York, Chicago, The World Railway Publishing Company · leaf 300
LOCOMOTIVE APPLIAXCES. 282 regular feed of oil to the bearings it is claimed to effect considerable saving of oil. Fig. 1 gives a general view of these devices as applied to the leading wheel of an engine truck; Fig. 2 shows the details of both the cellar and the oil cup. … u Fig. 4. Fig. 3. Acme Oil Cup. Acme Oil Cup. (Sectional View.) From the latter engraving it will be noted that no cellar-bolts are required, and hence none can be lost, as frequently occurs on the road with the ordinary form, but that the cellar is held up to the journal by four coil springs. By…
Railroads · Transportation
Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
