.The wheel was then lifted a given distance and supported by aprop. Moving the slide produced on the card a line indicatingthe height from which the wheel would fall. Tripping the propand moving the slide at the same time produced a series of zig-zag lines, as shown in the cut, each being lower… … Fig. 115.—Diagram illustrating- resfliometer record of a pneumatic tire, on wheel, droppedfrom a given distance to a one-inch round rod, and recorded as the resiliometer slideis moved. rebound above the lower line, as compared with the distancebetween the lines, was taken as the measure of the…
