Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 158
Fig. 120.—Elements of the Compound Hub of the Double Interacting Wheel. A is theouter hub plate, showing interior slot. B is one of the two floating guide plates, car-rying keys or splines, arranged on eitber side, as indicated. C is the central hubplate, also slotted, and arranged for hanging…
Automobiles
