y. It consisted of two parallel horizontal cylindricaldrums, set one above the other in the width of the carriage, sur-mounted by a third, a separator tube, and connected togetherby a number of tubes, each shaped like the letter U laid on itsside, and also, directly, by several vertical tubes. The… … Fig. 11.—Sectional Elevation of one of Golds-worthy Gurneys Early Coaches, showingwater tube boiler, directly geared cylinders and peg-rod driving wheel. to remedy the defects of Gurneys boiler with a water-tube gen-erator, designed by himself, in which the triple rows of parallelU-tubes were…
