Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 301
eakerOne terminal is at C, the other at pin, B. By depressing button, A;contact may be broken. By withdrawing pin, B, circuit may be in-terrupted, rendering it impossible to start the engine. disposition of their cranks in degrees. With such devices thespark may be timed, either by turning the… … Fig. 207.—Steering Wheel and Attachments of the Panhard-Levassor Car-riage. A, a shaft on a diameter of the wheel; B, a cylindrical fixed capwith toothed ends: C, C, a sleeve with toothed ends, F, F, in normalengagement with B, under tension of springs, E, E, being preventedfrom rotating; G, G,…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
