Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 380
the usual compression bands on TYPICAL GASOtim CARRiAGBS. 867 each of the rear wheel hubs, is operated by a hand lever atthe right of the drivers seat, outside of the change-speed lever.It normally stands upright, as shown in the cut, and is thrustforward in the act of setting the brakes. Except… … Fig. 279.—The Winton Two-cylinder Tonneau Car. The Winton Gasoline Carriage.—The well-known Wintoncarriage, formerly built with a single-cylinder motor, but now, insome models, with a double opposed cylinder, embodies many ex-cellent features. The front and rear axles are connected by tworeach rods…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
