Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 412
Fig. 305.—Elevation of Chassis of the Columbia Four-cylinder TonneauCarriage. … Fig. 306.—Plan of Chassis of the Columbia Four-cylinder Tonneau Carriage. cut to coarse pitch to facilitate engaging, giving four forwardspeeds and one reverse. A single lever slides all gears, including reverse. It operatesin a gridiron quadrant equipped with a hinged latch, preventingengaging the…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
