Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 433
fl , —~ .1 ! ( . … Fig. 323.—Sectional Elevation of the Cadillac Chassis, showing operative andcontrol apparatus, as explained in text. the casing, and the sprocket, A, forms part of it. When the brakedrum, H, with the pinion studs upon it, is held stationary by aband brake; and when pinion, D, turns with the shaft…
Automobiles
