ns in which it was produced. Thus, when water ischanged into the vapor known as steam/ by the action of heat,it will return to the liquid state if the temperature is allowed tofall sufficiently. For this reason, it is necessary to maintain thecylinders of a steam engine at a temperature, at least,… … Fig. 383. -A Simple Form of Steam Separator. The steam, admitted through the port atthe left of the figure, strikes against the screen in the centre of the chamber, thencefollowing the direction of the arrows. Any condensation settles in the bottGm of thechamber, whence it may be drawn off by the…
