Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 580

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 580 — Fig. 410. Fig. 411. Fig. 410.—Top View of the Ofeldt Boiler, showing the feed-water coil sur-rounding the generating coils; also attachments of generator coils. Fig. 411.—Side Elevation, showing steam chamber, generator coils andburner. heat of the burner, and control the circulation of the water.…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
