Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 596

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 596 — Figs. 426, 427.—Dial and Interior View of the American Duplex CombinedSteam and Air Pressure Gauge for Use on Steam Carriages. The dialhas two hands; one of them attached to a sleeve which works over thespindle carrying the other, in the same manner as the two hands of aclock are hung. As may be…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
