se openingsin the side elevation furnish a good opportunity for the student to utilize what he hasalready learned about projection. CONSTRUCTION DRAWING OF ENGINE. PLATE 34. This is a drawing of the complete Engine. It is commonly called the Construc-tion Drawing and is the original one made in… … MECHANICAL DRAWING. 49 by the designer. The Plate is to a scale of § to a foot, or one-sixteenth, and conse-quently many of the small parts and dimensions are obscure, so that in some casesreference will have to be made to the detail drawings. It is preferable to use a scale of 6 inches to the foot…
Mechanical drawing
