Lange, David C. (David Christoph) · New York, John Wiley & sons, inc.; [etc., etc.] · leaf 46
c, d, etc. 40. To find the intersection of a Cone with an obHqueplane. Let a Cone be cut by an oblique plane P. (Fig. 56.)Auxiliary Planes arc passed through the vertex of the Coneand p(M-pendicular to a coordinate, as R, S, T, etc. TheseAuxiliary Planes cut elements from the Cone which inter-sect… … 34 PRINCIPLES OF DESCRIPTIVE GEOMETRY points needed to determine the intersection are determinedin the same way. 41. To determine the intersection of a double-curvedsurface of revolution with a plane. Let the double-curved surface of revolution be cut bythe plane P. (Fig. 57.) Auxiliary Planes,…
Shades and shadows · Geometry, Descriptive
