Ship-building in iron and wood (1863)

Murray, Andrew, 1813-1872, Murray, Robert. Steam-ships, Creuze, Augustin Francis Bullock, 1800-1852 · Edinburgh : A. and C. Black · leaf 137

An illustration from Ship-building in iron and wood, 1863, leaf 137
Fig. 13.—Doable Piston-rod Screw-engine, l^irect. Fig. 15.—Screw-engines in the Royal Nary, Direct. STEAM SHIPS. 121

Naval architecture · Steamboats
