■■—Ends of Abrasivepaper bent overfo fif in groove.Wooden Cylinder Fig 255—Mounting abrasive paper or cloth on a small woodencylinder for use in the lathe head is shown in Fig. 255. This is a small cylinder ofwood, on the surfaces of which abrasive cloth or paperis held by cutting a slot lengthwise… … Fig. 256—A simple lapp board paper are forced. By passing a bolt through the centerof this cylinder it may be held in the chuck of the lathe,or, if it is not too long, it can be drilled out to fit thespindle of the grinding head. To give an instance of theuse of such a device, the writor once had a…
