Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 282
achineis ready to assemble. The bench clamping piece can be machined next.Owing to the size and shape of this piece it will be pos- Construction of Small Poirer Driven Drill Press 281 sible to mount it in the cliuelv and use the boring toolmounted in the tool post of the lathe. The casting… … iP|||fl1TpiT|ffltlTITIH|iWIfiti|ltl1Wl|lll1i|*l>llPfl<:1TlW!lifiT|ilPI1!P^^ Fig. 294—Squaring up the spindle bearing casting height so that the casting will revolve perfectly concen-tric with it. It should also be clamped tightly in the tool
Machine-shop practice · Handicraft
