Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 80
adjustable within \\ide limits. This is accom-plished by using what is knoAvn as the split die, that is,a die which is made in two pieces. The die stock is soarranged that it will hold these pieces in place and meansis also provided to adjust the blocks. Such a die stock,together mth an assortment… … Fig. 84—A split die and die stock 84. Owing to the long handles on such large die stocks,a powerful leverage is produced and it requires verylittle strength to produce threads on large rods of steel,brass or iron. Like taps, diesshould be well taken care of, and afterbeing used they should be…
Machine-shop practice · Handicraft
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
