Fig. 5. End Vid^v of Cylinder. but 1 pound. It has, however, driven a smalltorpedo boat, 4 feet long by 6 inches wide, atthe rate of 3 miles per hour with oil fuel underthe boiler; this latter will be shown in the chap- H SMALL ENGINES AND BOILERS. … Fig. 6. Small Vertical Engine. SMALL ENGINES AND BOILERS. 15 ters devoted to boilers. There are no figureddimensions on this engine, so the maker is left tofollow his own ideas in regard to them. As maybe seen, the columns are turned all over, andthreaded for nuts at each end. The holes in…
