Small engines and boilers; a manual of concise and specific directions for the construction of small steam engines and boilers of modern types ... for amateurs and others interested in such work (1899)
Watson, Egbert P. (Egbert Pomeroy) · New York, D. Van Nostrand company · leaf 33
between the holes cut out with asmall drift. It cannot be said of such engines that they areof any particular use ; but they serve as studiesin small work and close fitting-, for as this en-gine makes some 2,000 revolutions per minute,it must be well made to stand the racket. Theentire height of it… … SMALL ENGINES AND BOILERS. 17 views of the maker. The bed-plate is cast inone piece, faced in the lathe on the end wherethe cylinder is fastened, and has a single eccen-tric directly connected to the valve-stem withoutany rocker arm. A good proportion for it is tomake the cylinder r2 inch diameter…
Steam-engines
