Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)
Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 142
rator terminals. This system has not proved entirelysatisfactory and has not been used much in the last few years. Vibrating-Contact Regulator. Another regulating circuit whichvaries a resistance in series with a shunt field is the vibrating-contact type, similar in principle to the Tirrill… … Fig. 43. Delco Ignition Distributor and Generator as Used on 9-N Continental MotorCourtesy of Dayton Engineering Laboratories Company, Dayton, Ohio tacts which short-circuit a resistance in series with the shunt field.The action is as follows: If the car is running above the cut-inspeed the current…
Electric motors · Electric transformers · Electromagnets · Induction coils
