Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)

Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 143

An illustration from Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils, 1920, leaf 143 — GG- 2 GG-Z004 GG-5 A … Fig. 44. Auto-Lite Generator Parts as Used on Empire CarsCourtesy of Electric Auto-Lite Corporation, Toledo, Ohio the resistance in the shunt field of the generator and thus increasesthe charging rate. This compensates for the fact that not onlyis the drain on the battery greater during w^inter…

Electric motors · Electric transformers · Electromagnets · Induction coils

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
