Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)
Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 193
Fig. 19. Method of Assembling Transformer Core bolts should be used instead of screws to hold AB and the core.By holding the core as indicated, the primary and the second-ary coils may be slipped on over the two legs of the coreand the end strips inserted to complete the iron core. Thismethod of… … Fig. 20. Method of Clamping Transformer Core during Construction the coils at any time. The height of the two supporting blockswill need to be ascertained from the size of the transformer tobe built. The blocks should hold the core above the base at a 180 DESIGN OF SMALL TRANSFORMERS 37 sufficient…
Electric motors · Electric transformers · Electromagnets · Induction coils
