Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)

Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 74

An illustration from Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils, 1920, leaf 74 — At any instant of time the flux will bedistributed approximately sinusoidally. There will thus be fourregions in the air gap where the flux density is zero and fourwhere it is a maximum, and in the intermediate regions theflux density will be intermediate in value in the same propor-tion as the…
