y feed issecured. A similar clutch is used in the Weston lamp. Clutch, Electro=magnetic. A clutch or appliance for connect-ing a shaft to a source of rotary motion while the latter is in action. STANDARD ELECTRICAL DICTIONARY. 129 In one form a disc, in whose face a groove has been formed,… … Fig. 93. Clutch of Brush Lamp. wheel to partake of the motion of the shaft. Contact is made bybrushes and collecting rings. In the cut, A A is the attracted disc ; the brushes, B B} take cur-rent to the collecting rings, C. The magnetizing coil is embeddedin the body of the pulley, as shown.
