net,conical in shape and rather deep, towhose apex two threads, one on eachside, are attached. Its mouth is fast-ened to a vertical ring and the whole ismounted on an insulating support. It is pulled out to its full extent andis electrified. No charge can be detectedinside it. By pulling one of the… … Fig. i Faradays Net. Faradays Transformer. The first transformer. It was madeby Michael Faraday. It was a ring of soft iron 7/% inch thick,and 6 inches in external diameter. It was wound with bare wire,calico being used to prevent contact of the wire with the ring andof the layers- of wire with…
