The standard electrical dictionary; a popular dictionary of words, terms, and phrases, used in the practice of electrical engineering (1897)

Sloane, T. O'Conor (Thomas O'Conor), 1851-1940 · New York, H. W. Henley & co. · leaf 367

An illustration from The standard electrical dictionary; a popular dictionary of words, terms, and phrases, used in the practice of electrical engineering, 1897, leaf 367 — Fig. 230. Magneto-Electric Generator. The cut, Fig. 230, shows the general principle of constructionof a direct current generator. The armature is rotated between … Fig. 231. Magneto-Electric Generator.the poles of a permanent magnet. Any of the regular types ofdynamo armature can be used. From its commutator the currentis taken by brushes. STANDARD ELECTRICAL DICTIONARY. 363 The cut, Fig. 231, shows an alternating current machine. In ita pair of bobbins,…

Electricity

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
