The standard electrical dictionary; a popular dictionary of words, terms, and phrases, used in the practice of electrical engineering (1897)

Sloane, T. O'Conor (Thomas O'Conor), 1851-1940 · New York, H. W. Henley & co. · leaf 49

An illustration from The standard electrical dictionary; a popular dictionary of words, terms, and phrases, used in the practice of electrical engineering, 1897, leaf 49 — ¥ig. 24. Disc Armature of Fritsche Machine,1 … Fig. 25. Plan of Winding Pacinottis Disc Armature.Armature, Discoidal Ring. In a dynamo an armature of the STANDARD ELECTRICAL DICTIONARY. 45 shape of a ring of considerable radial depth of section as comparedto its axial depth. It is generally made of iron ribbon or thinband wound to the proper…

Electricity

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
