wn as the A side,that on the right as the B side of the apparatus. Kx, the reversing key, reverses the direction of the current. K2is a simple key, known as the increment key ; it is used simply toincrease the strength of the current. The way in which the keys Kx and K2 combine their action isshown… … Fig. 320. Quadruplex Telegraph Connections. whole combined battery will be 3.3 Ex. The negative pole of Elis connected to z and zx of Kx, and the positive pole of E2 to a ofK2 through a resistance coil s. A wire, called the tap wire, con-nects the positive pole of Ex and the negative pole of E2 to…
