The standard electrical dictionary : a popular encyclopaedia of words and terms used in the practice of electrical engineering (1898)
Sloane, T. O'Conor (Thomas O'Conor), 1851-1940 · London : Crosby Lockwood and Son · leaf 321
the poles TV 6, of a powerful compound horseshoe magnet, G G.It is wound with fine wire and a key handle H is provided forworking it. In its normal position the handle is drawn upward,and the end S S ai the armature core is in contact with the southpole 6 of the permanent magnet, and the end D D… … 3i6 STANDARD ELECTRICAIv DICTIONARY. the north pole. This suddenly reverses the polarity of the arma-ture and sends a momentary current through the armature coilwhich is in circuit with the line. The cut only shows the principleof the key, whose construction is quite complicated. Key, Make and…
Electricity
Internet Archive · Medical Heritage Library · Public Domain Mark 1.0. Free to use for anything.
