The standard manual of dynamos and practical application of dynamo-electric machinery (1915)
MacFadden, Carl K. [from old catalog], Ray, William D., [from old catalog] joint author · Chicago, Laird & Lee, inc. · leaf 60
n Fig. 20 is a simple multiple plan of wiringFig. 21 shows the same number of lamps but they aresupplied by two dynamos Di, D2, each of half thecapacity in amperes but the same voltage as dynamoD inFig. 20. Thus with the 5 lamps connected to eachdynamo, there will be 5 amperes flowing out from… … 6UTI Jit^H? FIGURE 23.—EDISON 3 WIRE SYSTEM SUPPI^YING10 I.AMPS. that the 110 volt lamps may be connected in series of twoand give their proper candle power as shown in Fig. 22.The current flowing out from the positive brush of Diwill be but 5 amperes, for there are now 5 series of 2lamps each,…
Electrical engineering · Electric machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
