Stationary steam engines; especially as adapted to electric lighting purposes (1884)
Thurston, Robert Henry, 1839-1903 · New York, J. Wiley & sons · leaf 104
in regulation. Separate valves are seen at eachend of the cylinder, and the clearance and dead spaceis thus reduced to a minimum. This last provision makesit possible to cushion the exhaust steam up to boiler pres-sure on the return stroke, and thus to secure a minimumwaste by condensation on the… … o; 10; \o 9) — (9. O: CO ; i 01 r:^6>jz±vo rooB JT«L Cylinder; Elevation and Section. nals and bearings may be taken up, in any case, withoutaltering, to any observable extent, the position of the pistonin the cylinder, and this permits small cylinder clearance,also. For the reason above given,…
Steam-engines
