Stationary steam engines, simple and compound; especially as adapted to light and power plants (1899)
Thurston, Robert Henry, 1839-1903 · New York, J. Wiley & Sons; [etc., etc.] · leaf 247
ap and the weight sof the gov-ernor ; wliile a pin, E, set in the cover-plate, actuates thevalve as usual. The center of the eccentric is so locatedthat its motion relatively to the wheel, as produced by thegovernor, causes E to describe an arc about the eccentric-centre giving the desired… … Triple-expansion DiAokAM. in the governor, the dash-pot should be introduced as in theillustration. The method of assemblage is well shown bythe peculiar method of engraving the latter figure, a methodintroduced by Westinghouse. The diagram here reproduced illustrates a good adjust- ELECTRIC…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
