Stationary steam engines, simple and compound; especially as adapted to light and power plants (1902)
Thurston, Robert H[enry], 1839-1903. [from old catalog] · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 247
p and the weight sof the gov-ernor ; while a pin, E, set in the cover-plate, actuates thevalve as usual. The center of the eccentric is so locatedthat its motion relatively to the wheel, as produced by thegovernor, causes jE to describe an arc about the eccentric-centre giving the desired variation… … Triple-expansion Diagram. in the governor, the dash-pot should be introduced as in theillustration. The method of assemblage is well shown bythe peculiar method of engraving the latter figure, a methodintroduced by Westinghouse. The diagram here reproduced illustrates a good adjust- ELECTRIC…
Steam-engines
