Stationary steam engines, simple and compound; especially as adapted to light and power plants (1902)
Thurston, Robert H[enry], 1839-1903. [from old catalog] · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 67
ntages over the old,in keeping the working parts, and especially the joints, outof the steam space. The exhaust valves are gridiron slides,set to travel across the line of the cylinder, and driven from 1. Supplied by D. Appleton & Co. 44 STEAM ENGINES FOR a horizontal rock-shaft, extending… … Greene Trip Motion. The tappets, A^ A, are carried by the rock-shafts, J,J, which, in turn, drive the arms, F^ F, and the valvesattached to the stems, G, G, passing through the stuffingboxes, H, H; the tappets, B^ £, engage these rock-levers,and are adjusted vertically by the governor rod, F>,…
Steam-engines
